Features
· Fast and Precise Framing |
· Motorized linearly auto focus, iris and zoom (8°-55°) |
· The gobo wheel can automatically synchronize the focus |
· Use high-precision multi-group cemented lens; beam sharp and spot uniform; high pattern definition and color consistency from center to edge |
· LED module white with high luminous flux; lifespan up to 50000 hours |
· Perfect for most large performing venues and event productions such as music festivals, theaters, and exhibitions, etc. |
Parameter
Operating Voltage | AC100-240V, 50/60HZ |
Rated Power | 700W |
Light Source | LED module 600W white |
Beam Angle | 8°-55° |
Front Lens Diameter | 124MM |
Channel | 38/31 |
Color Temperature | 7000K |
Color System | Smooth CMY color mixing with CTO filter (3200K) + 8 colors + blank; with half color, water and rainbow effects; with macro |
Fixed Gobo Wheel | 6 fixed gobos + blank, bi-directional shaking and scrolling at variable speed |
Rotating Gobo Wheel | 6 replaceable gobos + blank, bi-directional shaking and scrolling at variable speed |
Cutting Module | Four independently controllable 90° rotating framing shutter blades, with macro |
Prism | 1 x 3-facet prism and 1 linear prism; both can bi-directional rotate at variable speed |
Frost | 1 frost filter, with macro |
Dimming | 0-100% Electronic linear adjustable dimmer without flicker |
Strobe | Electronic 1-25 Hz, speed adjustable |
Movement | Pan 540°, 3.8 seconds, Tilt 270°, 2 seconds; 16-bit; auto position correction with 3-phase stepping motor |
Overheat Protection | Automatic power-off protection when overheated |
Cooling | With axial fans |
IP Rating | IP20 |
N.W. | 31.55KG |
