Features
· Energy Saving——Power consumption cut by 50% when close the shutter |
· Motorized linearly focus |
· Rich prism effects to achieve strong artistic creativity |
· Use high-precision multi-group cemented lens |
· Using magnetic encoder positioning, more accurate than optocoupler |
Parameter
Operating Voltage | AC 100-240V, 50/60HZ |
Rated Power | 530W |
Light Source | 17R 350W |
Lifespan | 1500H |
Beam Angle | 2.2° |
Front Lens Diameter | 170MM |
Channel | 18 |
Color Temperature | 8000K |
Color System | 1 rainbow effect wheel; 11 colors (with CTO 3200K filter + CTB 5600K filter) + blank, with half color and water effects |
Fixed Gobo Wheel | 16 fixed gobos + blank, bi-directional scrolling and shaking at variable speed |
Prism Wheel 1 | 1 linear prism + 1 x 48-facet prism + 1 x 24-facet prism; bi-directional rotate at variable speed; with macro |
Prism Wheel 2 | 1 linear prism + 1 x 16-facet prism + 1 x 32-facet prism; bi-directional rotate at variable speed; with macro |
Frost | 1 frost filter |
Dimming | 0-100% Electronic linear adjustable dimmer without flicker |
Strobe | Double-piece strobe 0-13 Hz, speed adjustable, the lamp will drop power when the strobe off |
Movement | Pan 540°, 2.2 seconds; Tilt 270°,1.2 seconds; 16-bit precise scanning; 3-phase noise-free stepping motor |
Overheat Protection | Automatic power-off protection when overheated |
Cooling | With axial fans |
IP Rating | IP55 |
