Input Voltage
AC100-240V, 50/60Hz
Light Source
7x15W RGBW 4-in-1 LED
Color Temperature
2500K-8000K linearly adjustable
LED Expected Lifespan
50,000 hours
Horizontal 540°, Vertical 210°
With automatic error correction reset function
It adopts a noiseless three-phase motor, optocoupler, and Hall positioning, operates smoothly and has accurate positioning
Zoom Range
4°- 60°
0-100% electronic linear dimming, smooth and flicker-free
Electronic strobe 1--25 times/HZ, speed adjustable
5 Channel Modes
1) Standard mode: 21CH
2) Shape mode: 35CH
3) Extended mode: 42CH (A variety of built-in effects can be pre-stored in the channel)
4) RGBW extended mode: 49CH
5) Full mode: 56CH
Control Modes
DMX512/Master-Slave
Standard 3-pin and 5-pin XLR signal interface
1
LCD color screen + rotary encoder, LED temperature display, bilingual in Chinese and English
Adopt die-cast aluminum heat sink
1
IP20
Product Size
337 x 244 x 402 mm
Product Net Weight
10.5 kgs
Each LED can be separately controlled High transmittance acrylic light guide rod and aspheric lens With external network interface On the premise of having the functions of light beam, pattern, dyeing, etc., there are rich effect modes (vortex, kaleidoscope, small waist); the front mirror plate can be rotated in two directions; can realize instant dark […]
On the premise of having the functions of light beam, pattern, dyeing, etc., there are rich effect modes (vortex, kaleidoscope, small waist); the front mirror plate can be rotated in two directions; can realize instant dark field effect; it provides lighting designers with highly flexible creative space, while achieving cost optimization.
Each LED can be separately controlled High transmittance acrylic light guide rod and aspheric lens With external network interface
