This is a beam light that combines beam, pattern and wash functions to meet the diverse needs of stage lighting. It not only has excellent performance and high-cost performance, but also has a unique large focusing angle, so that the projected pattern can cover a wider area and bring shocking visual effects. It is suitable for various medium and small-scale performances and event scenes.
Input Voltage
AC110-240V, 50/60Hz
Whole Lamp Power
500W
Light Source
Yodn 350W
Optical Aperture
108mm
Color Temperature
8000K
Bulb Expected Lifespan
1500 hours
1
Horizontal 540° 2.6 sec, Vertical 270° 1.4 sec (16-bit)
2
With automatic error correction reset function
3
It adopts a noiseless three-phase motor, optocoupler, and Hall positioning, operates smoothly and has accurate positioning
1 Color Wheel
11 colors + blank
1 rainbow color plate
1 Rotating Gobo Wheel
7 plug-in rotating gobos + blank, with pattern shaking and water effects. The entire gobo wheel and each individual glass gobo can rotate at variable speeds in both directions
1 Fixed Gobo Wheel
14 fixed gobos + blank, with pattern shaking and water effects. The entire gobo wheel can rotate at variable speeds in both directions
1 Dynamic Gobo Wheel
4 fixed gobos + blank, with pattern shaking and water effects. The entire gobo wheel can rotate at variable speeds in both directions
Zoom Range
2.2°- 50°
With autofocus function
One 8+16-facet prism + one 24-facet prism, can rotate at variable speeds in both directions
1 mist lens
0-100% electronic linear dimming, smooth and flicker-free
Strobe 1--13 times/HZ, speed adjustable
1 Channel Mode
22 CH
Control Modes
DMX512/Master-Slave
Standard 3-pin XLR signal interface
1
LCD color screen + rotary encoder, bilingual in Chinese and English
1
With electronic temperature control overheating protection
2
Axial fans are used to enhance ventilation and cooling
1
IP20
Product Size
395 x 288 x 642 mm
Product Net Weight
23 kgs
